PRECISELY CALCULATED ENCLOSURE
Specifically optimised for wake boat applications with longer throw, greater cut through and optimum air volumes, the Signature Series 3 wake tower speakers reproduce crystal clear, high-performance audio at all volume levels.
CURV CONE TECHNOLOGY
CURV is a woven fibre composite that is heat pressed to form a lighter and stronger cone. This delivers greater sound definition and higher output while providing increased protection from marine conditions.
SILK DOME TWEETER
The silk dome tweeter provides a smooth upper-frequency response and increased efficiency, which delivers crystal-clear music reproduction.
LARGE-DIAMETER VOICE COIL
Delivering an increase in real power and efficiency, the large diameter voice coil provides a signature sound exclusive to the Signature Series 3 wake tower speakers.
FULLY SEALED CROSSOVER COMPONENTS
Fully sealed crossover components provide full protection from the harsh marine environment. This delivers an improved frequency response at the crossover point for a detailed audio spectrum and a new level of acoustic performance.
General |
|
Physical dimensions (Diameter x Depth) | 8.8": 8.82" x 15.16" (224 x 385 mm) 7.7": 7.72" x 12.91" (196 x 328 mm) 6.5": 6.93" x 11.97" (176 x 304 mm) |
Water and dust rating | IP65 |
Configuration | coaxial |
Speaker size | 6.5", 7.7" and 8.8" |
Peak power (Watts) | 8.8": 330 W 7.7": 280 W 6.5": 230 W |
RMS power (Watts) | 8.8": 130 W 7.7": 100 W 6.5": 75 W |
Sensitivity (1 W / 1 m) | 8.8": 91 dB 7.7": 91 dB 6.5": 90 dB |
Frequency response | 8.8": 50 Hz-20 kHz 7.7": 60 Hz-22 kHz 6.5": 70 Hz-22 kHz |
Nominal impedance | 4 ohms |
Recommended amplifier power (RMS) | 8.8": 25-140 W/Ch 7.7": 25-120 W/Ch 6.5": 30-90 W/Ch |
LED lighting | yes (CRGBW) |
LED supply voltage | 10.8-16 VDC |
LED load current @ 14.4 VDC | 300 mA |
Operating temperature range | 32° to 122° F (0° to 50° C) |
Voice coil diameter | 8.8": 1.5" 7.7": 1.4" 6.5": 1.2" |
Cone material | CURV cone with rubber surround |
Tweeter type | Silk dome |
Compass-safe distance | 8.8": 162" (412 cm) 7.7": 141" (358 cm) 6.5": 122" (310 cm) |
Warranty | 3 years |
SKU | FUS.010-02439-01 |
Model # | 010-02439-01 |
UPC/EAN | 0753759254872 |
Brand | Fusion |
Shipping Weight | 8.6200kg |
Shipping Width | 0.196m |
Shipping Height | 0.328m |
Shipping Length | 0.196m |
Shipping Cubic | 0.012600448m3 |
Unit Of Measure | ea |
