About Invicta Lithium

The Invicta Lithium 12V range has been specifically designed for replacement of similar size Lead acid batteries. The family is comprised of the popular sizes found in the lead acid range but with the added benefits of Lithium Iron Phosphate (LiFePO4) technology and is ideally suited to deep cycle longer run time applications.

Features & Benefits

  • Large number of cycles >2000 (100% DoD) - Up to 8 times the cycle life of SLA lowering your total cost of ownership
  • Safe and stable chemistry & Integrated BMS - The use of LiFePO4 along with the integrated BMS ensures protection against overcharge/discharge, temperature and short circuits providing the highest degree of safety
  • Greater capacity utilisation – 60% more than SLA - Gives longer runtime than equivalent SLA
  • High energy density (less than half of the weight of SLA) - Lowering total weight of application
  • Fast recharge - Battery is charged and ready to be used sooner
  • Flat Discharge Curve - Longer run time & more efficient use of capacity
  • Extremely low self-discharge rate - Can sit unused for longer periods
  • UL1642 at cell level
Nominal Voltage 12.8v
Nominal Capacity (250C, 0.33C) 9Ah
Terminal F2
Length (mm) 151 ± 2mm
Width (mm) 65 ± 2mm
Height (mm) 95 ± 2mm
Weight 1.2kg
Max Charge Voltage 14.6 ± 0.1V
Standby 13.8 ± 0.1V
Cut off Voltage 10V
Max. Discharge Current 9A
Max. Pulse Discharge Current (3 Sec) 35A
Max. Charge Current 9A
Recommended Current Charge ≤ 5A
Cycle Life (100% DoD) ≥ 2000
Operating Temp - Charge 0 - 50°C
Operating Temp - Discharge -20 - 55°C
Short Circuit Release Load Release
Max. Series / Parallel Configuration 4P
SKU SEN.SNL12V9
Brand Invicta Lithium
Shipping Weight 1.6000kg
Unit Of Measure Each
