Victron AGM Super Cycle Batteries

A truly innovative battery

The AGM Super Cycle batteries are the result of recent battery electrochemistry developments. The paste of the positive plates is less sensitive to softening, even in case of repeated 100% discharge of the battery, and new additives to the electrolyte reduce sulfation in case of deep discharge.

Exceptional 100% depth of discharge (DoD) performance

Tests have shown that the Super Cycle battery does withstand at least three hundred 100% DoD cycles. The tests consist of a daily discharge to 10,8V with I = 0,2C₂₀, followed by approximately two hours rest in discharged condition, and then a recharge with I = 0,2C₂₀.

The two hours rest period in discharged condition will damage most batteries within 100 cycles, but not the Super Cycle battery. We recommend the Super Cycle battery for applications where an occasional discharge to 100% DoD, or frequent discharge to 60-80% DoD is expected.

Smaller and lighter

An additional advantage of the new chemistry is a slightly smaller size and less weight compared to our standard deep cycle AGM batteries.

Low internal resistance

The internal resistance is also slightly lower compared to our standard deep cycle AGM batteries

Compare to Lifeline Batteries

These are an excellent alternative to Lifeline deep cycle batteries. In a similar case size, Victron Super Cycle batteries offer a higher capacity at a lower price. They utilise screw terminals that easily accommodate conventional cable lugs.  Victron offers a limited two-year full replacement warranty where Lifeline has a 5-year limited pro-rata warranty.

Victron Super Cycle Lifeline Deep Cycle
Battery L x W x H mm Capacity AH Battery L x W x H mm Capacity AH
BAT412110081 260x168x215 100 GPL-24T 283x168x235 80
BAT412112081 330x171x214 125 GPL-31T 328x172x236 105
BAT412117081 336x172x280 170 GPL-30HT 342x172x304 150
BAT412123081 532x207x218 230 GPL-4D 528x221x220 210



5 Products Found
