• Conductor: Fine stranded annealed tinned copper to IEC 60228 Class 5&6 and AS/NZS 1125.
  • Insulation: LSFLEX® R-125 (X-HF-110), Cross-linked, Thermoset, Elastomeric, Low Smoke, Zero Halogen. 1250C max operating temperature conforms to UL1581.
  • Ripcord: High strength ripcord under sheath.
  • Sheath: LSFLEX® S-40 (HFS-110-TP), Flame Retardant, Cross-linked, Thermoset, Elastomeric, Low Smoke Zero Halogen. Splash resistant to oil, skydrol, petrol, acid and sea water. Resists ozone and UV. Excellent abrasion resistance.
  • Operating Temperature: -40°C to +125°C
  • Voltage Rating: 600/1000 Volts
  • Colours: Green/Yellow, Blue, Brown
  • Standards: AS/NZS 1125 AS/NZS 1660.5.1 AS/NZS 1660.5.2 AS/NZS 1660.5.4 AS/NZS 1660.5.6 AS/NZS 5000.1 IEC 60228 IEC 60332-1 IEC 60332-3(A) IEC 60754-2 IEC 61034-1&2 BS 5467
Brand Triangle Cables
Shipping Weight 0.0100kg
Unit Of Measure m
