Enhanced AIS Visibility Using Dual-Interface Connectivity and Smart Configuration

This AIS transponder offers seamless integration with modern navigation systems, providing both Wi-Fi and NMEA 2000 interfaces. It enables real-time vessel tracking and collision avoidance by transmitting your boat's position and identity to other AIS-equipped vessels. The device creates a secure, password-protected local Wi-Fi network, allowing AIS and GPS data to be sent to popular iOS and Android apps. Configuration is straightforward via a built-in web interface accessible through any browser, eliminating the need for additional software. Installation is simplified with an integral NMEA 2000 drop cable and compatibility with existing VHF antennas using optional splitters.

Key Features

  • Dual connectivity options: Provides both Wi-Fi and NMEA 2000 interfaces for versatile integration with tablets, PCs, and multifunction displays.
  • Secure wireless networking: Establishes a password-protected local Wi-Fi network for safe data transmission to mobile devices.
  • User-friendly configuration: Features a built-in web interface for easy setup and customization without additional software.
  • Real-time data sharing: Transmits AIS and GPS data to compatible apps, enhancing situational awareness and safety.
  • Flexible installation: Includes an integral NMEA 2000 drop cable and supports connection to existing VHF antennas via optional splitters.
  • Class B+ performance: Utilizes SOTDMA technology with a 5W power output for improved transmission reliability and range.​

Designed for modern mariners, this transponder delivers reliable AIS functionality with flexible connectivity options.

General
Transponder Class Class B+ (SOTDMA)
Power Output 5W
Interfaces Wi-Fi, NMEA 2000
Wi-Fi Protocols TCP/IP, UDP
Max Wi-Fi Connections 7 devices
Enclosure IP54 rated
Dimensions 180 × 145 × 40 mm
Weight 224 g
Performance
GPS Antenna External (included)
Update Rate Up to every 5 seconds
Supported Targets ATONs, AIS MOB devices
Installation
Power Supply 12/24V DC
NMEA 2000 Cable Integral drop cable
VHF Antenna Connection BNC connector
Optional Accessories SPL1500/SPL2000 antenna splitters
SKU DIG.ZDIGIAISTXPL
Model # ZDIGIAISTXPL
Brand Digital Yacht
Shipping Weight 1.2000kg
Shipping Width 0.340m
Shipping Height 0.110m
Shipping Length 0.240m
Shipping Cubic 0.008976000m3
Unit Of Measure each
