Connect marine navigation data seamlessly across onboard networked devices

The Digital Yacht LANLink NMEA 2000 to Ethernet Gateway enables NMEA 2000 data to be shared across an onboard Ethernet network, allowing charting applications, navigation software, monitoring systems, and connected devices to access real-time vessel data. Supplied with an iKonvert NMEA 2000 gateway, LANLink integrates directly with an existing NMEA 2000 backbone and transfers navigation, AIS, GPS, and instrument data through a standard Ethernet connection. With support for both TCP/IP and UDP communications, bidirectional data transfer, and a browser-based configuration interface, it provides a simple and flexible solution for integrating marine electronics with onboard networks and connected applications.

Key Features

• NMEA 2000 to Ethernet Integration: Connects a vessel’s NMEA 2000 network to Ethernet-based devices and onboard router networks for seamless data sharing.
• Supplied with iKonvert Gateway: Includes an NMEA Certified iKonvert interface for straightforward connection to NMEA 2000 backbones.
• Bidirectional Data Communication: Supports two-way data transfer between connected devices and the NMEA 2000 network.
• TCP/IP and UDP Support: Offers flexible network communication modes for compatibility with a wide range of marine applications and systems.
• Multi-Device Connectivity: Supports up to five simultaneous connected devices when operating in TCP/IP mode.
• Browser-Based Configuration: Features an intuitive web interface for setup and management without requiring additional software.
• Raw and Conversion Modes: Supports encapsulated PGN data for advanced applications or converted AIS, GPS, and instrument data for compatible software.
• Ethernet Network Connection: Connects easily to routers, switches, and network devices using a standard RJ45 Cat 5/6 Ethernet cable.
• RS232 Connectivity: Includes an RS232 interface for integration with compatible PC-based applications.
• Status Monitoring LEDs: Provides visual indication of power, network activity, data transfer, and system status for easy troubleshooting.

Designed for modern connected vessels, LANLink provides a practical solution for distributing NMEA 2000 data throughout onboard Ethernet networks and compatible marine applications.
