High-Performance 6-channel Amplifier for Premium Marine Audio

The Fusion Apollo 6-Channel Marine Amplifier delivers 150 watts RMS per channel, providing robust and clear audio across your boat. Designed specifically for marine environments, this Class-D amplifier features Fusion's Easy Tune setup for optimal sound quality without manual adjustments. Its ignition-protected design and conformal-coated circuit board ensure durability and safety on the water.​

Key Features

  • 150-watt RMS per channel: Provides powerful, clear audio to elevate your onboard listening experience.
  • Easy Tune setup: Automatically adjusts audio settings for optimal sound quality without manual tuning.
  • Class-D amplifier: Offers high efficiency with minimal distortion and reduced battery drain.
  • Marine-grade durability: Conformal-coated circuit board and ignition protection safeguard against harsh marine conditions.
  • LED indicators: Allow quick identification of electrical issues such as shorts or overheating.
  • Compact design: Includes mounting brackets for straightforward installation in various marine setups.​

Enhance your marine audio system with the Fusion Apollo™ 6-Channel Marine Amplifier, delivering powerful performance and reliable durability for your on-water adventures.

General Specifications
Product Type 6-Channel Marine Amplifier
Part Number 010-02284-65
Amplifier Class Class-D
CEA-2006 Power Rating 150-watt RMS x 6 @ 14.4 V input – 4 ohm < 1% THD
Total Rated Power Output – 2 ohm 290-watt RMS x 6 @ 14.4 V input – 2 ohm < 1% THD
Total Rated Power Output – 4 ohm Bridged 580-watt RMS x 3 @ 14.4 V input – 4 ohm Bridged < 1% THD
Peak Power 1800 watts
Input Sensitivity 1.6 V RMS
Input Impedance 22k ohm
Operating Voltage 10.8 V – 16 V DC
Current Draw (Standby/Off) < 5 mA @ 14.4 V input
Current Draw (No Audio) < 1.32 A @ 14.4 V input
Fuse Rating 125 A electronic fuse (no replacement necessary)
Power-Cable Fuse Model and Rating Bussmann™ BK/AMI-030 30 A fast-acting
Ignition Safety Protected (SAE J1171) Yes
Protection Circuits Reverse voltage, input under/over voltage, over temperature, output short circuit
Operating Temperature Range 32° to 122° F (0° to 50° C)
Water Rating IPX2
Physical Dimensions (without bracket) 11.69″ x 7.06″ x 1.75″ (297 x 180 x 45 mm)
Physical Dimensions (with bracket) 11.69″ x 7.06″ x 2.13″ (297 x 180 x 50 mm)
Weight 5.95 lb (2.7 kg)
SKU FUS.010-02284-65
Model # 010-02284-65
UPC/EAN 753759329624
Brand Fusion
Shipping Weight 4.0000kg
Unit Of Measure each
