High-Efficiency Monoblock Amplifier for Powerful Marine Audio

The Fusion Apollo Monoblock Marine Amplifier delivers 650 watts RMS of high-efficiency power, enhancing your marine audio system with robust bass performance. Designed specifically for marine environments, this Class-D amplifier features Fusion's Easy Tune setup for optimal sound quality without manual adjustments. Its ignition-protected design and conformal-coated circuit board ensure durability and safety on the water.​

Key Features

  • 650-watt RMS output: Provides powerful, clear bass to elevate your onboard audio experience.
  • Easy Tune setup: Automatically adjusts audio settings for optimal sound quality without manual tuning.
  • Class-D amplifier: Offers high efficiency with minimal distortion and reduced battery drain.
  • Marine-grade durability: Conformal-coated circuit board and ignition protection safeguard against harsh marine conditions.
  • LED indicators: Allow quick identification of electrical issues such as shorts or overheating.
  • Compact design: Includes mounting brackets for straightforward installation in various marine setups.​

Enhance your marine audio system with the Fusion Apollo™ Monoblock Marine Amplifier, delivering powerful performance and reliable durability for your on-water adventures.

General Specifications
Product Type Monoblock Marine Amplifier
Part Number 010-02284-15
Amplifier Class Class-D
CEA-2006 Power Rating 650-watt RMS x 1 @ 14.4 V input – 4 ohm < 1% THD
Total Rated Power Output – 2 ohm 1100-watt RMS x 1 @ 14.4 V input – 2 ohm < 1% THD
Peak Power 2000 watts
Input Sensitivity 2.15 V RMS
Input Impedance 22k ohm
Operating Voltage 10.8 V – 16 V DC
Current Draw (Standby/Off) < 5 mA @ 14.4 V input
Current Draw (No Audio) < 1.15 A @ 14.4 V input
Fuse Rating 125 A electronic fuse (no replacement necessary)
Power-Cable Fuse Model and Rating Bussmann™ BK/AMI-030 30 A fast-acting
Ignition Safety Protected (SAE J1171) Yes
Protection Circuits Reverse voltage, input under/over voltage, over temperature, output short circuit
Operating Temperature Range 32° to 122° F (0° to 50° C)
Water Rating IPX2
Physical Dimensions (without bracket) 9.25″ x 7.06″ x 1.75″ (235 x 180 x 45 mm)
Physical Dimensions (with bracket) 9.25″ x 7.06″ x 2.13″ (235 x 180 x 50 mm)
Weight 4.85 lb (2.2 kg)
SKU FUS.010-02284-15
Model # 010-02284-15
UPC/EAN 753759329600
Brand Fusion
Shipping Weight 3.2000kg
Unit Of Measure each
