DESIGNED AND ENGINEERED FOR THE MARINE ENVIRONMENT

The EL Series speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog and UV.

DESIGNED TO COMPLY WITH ISO12216

Tested to international standards for pressure and water ingress, the EL Series speakers are designed and built for superior quality and robustness.

QUALITY MATERIALS AND ACOUSTIC ENGINEERING

The EL Series speakers incorporate high-quality materials and marine-specific design elements, ensuring they look and sound great on the water.

INJECTION-MOULDED POLYPROPYLENE (IMPP) CONE

By using a water-resistant IMPP cone it improves the robustness of the speaker, allowing for clean, clear audio reproduction.

LIGHTWEIGHT VOICE COIL

The lightweight design allows for higher sensitivity, resulting in increased power and efficiency to deliver an enhanced audio experience.

OPEN BASKET CONSTRUCTION

The optimised open back design allows for extended power handling and versatile mounting options with reduced mounting depth.

MULTICOLOUR RGB LED LIGHTING

The sports-style EL Series speakers with RGB LED lighting provide bright and even LED illumination in a wide range of colours, letting you choose any colour to match the mood and enhance your audio entertainment experience.

CONTROLLING THE RGB LIGHTING

Control the colour (static or dynamic), brightness, light mode and speed by using the optional MS-RGBRC wireless remote control (sold separately).

FEATURES:

  • Experience multicolour RGB LED lighting (sports style LED model only) to brighten up your boating experience.
  • The injection-moulded polypropylene cone provides clean, clear audio reproduction.
  • The shallow basket design provides increased versatility during installation.
  • The speakers are available in a 6.5″ design with both classic and sports style grilles.
  • Salt fog resistant and UV stable design for the harsh marine environment.

General

Weight Classic: 1.21 lbs (0.55 kg)
Sports: 1.26 lbs (0.57 kg)
Physical dimensions (diameter x depth) Classic: 6.93″ x 2.26″ (176 x 57.5 mm)
Sports: 6.93″ x 2.32″ (176 x 59 mm)
Water and dust rating IP65
Configuration Full range
Speaker size 6.5″
Peak power (Watts) 80 W
RMS power (Watts) 20 W
Sensitivity (1 W / 1 m) 91 dB
Frequency response 45 Hz-16 kHz
Nominal impedance 4 ohms
Recommended amplifier power (RMS) 20-40 W/Ch
LED lighting Yes, RGB (sports-style only)
LED supply voltage 10.8-16 VDC (sports style only)
LED load current @ 16 VDC 150 mA (sports style only)
Operating temperature range 32° to 122° F (0° to 50° C)
Voice coil diameter 0.79″
Cone material Polypropylene cone with cloth surround
Compass-safe distance 100″ (254 cm)
Warranty 1 year

Mounting dimensions

Mounting diameter clearance 5.12″ (130 mm)
Mounting depth clearance 1.69″ (43 mm)
SKU FUS.010-02080-11
Model # 010-02080-11
UPC/EAN 753759314156
Brand Fusion
Shipping Weight 0.5500kg
Shipping Width 0.176m
Shipping Height 0.057m
Shipping Length 0.176m
Shipping Cubic 0.001766000m3
Unit Of Measure ea
