ULTRA HIGH-DEFINITION SCANNING SONAR

Get built-in Ultra High-Definition SideVü and ClearVü™ scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP® X3 series also supports 1 kW CHIRP traditional sonar capabilities.

PANOPTIX™ SONAR SUPPORT

Pair with Panoptix or LiveScope™ easy-to-interpret live sonar (transducer required, sold separately) to see all around your boat in real time.

FASTER, SHARPER, SMARTER

With its added processing power and new slimline design featuring edge-to-edge glass and a smaller unit footprint, it’s easy to retrofit this plotter in a wider range of dash configurations.

IMPROVED DISPLAY OPTICS

New higher-resolution IPS displays for 9” and 12” plotters offer improved sunlight readability and visibility from any angle, with 50% more pixels than previous-generation 9” GPSMAP devices.

PRELOADED MAPPING

Experience unparalleled coverage and detail with built-in Garmin Navionics+ integrated coastal and inland mapping that includes Auto Guidance+™ technology3 and a 1-year subscription for downloadable daily updates and more on select chartplotters.

OPTIONAL CHARTS AND MAPS

Bring a fresh new look and feel to your chartplotter with optional upgrade to Garmin Navionics Vision+™ premium chart subscription, featuring downloadable high-resolution relief shading, satellite imagery, sonar imagery and more.

OPTIONAL RADAR BUNDLE

To help you avoid weather and traffic on the water, the compact 4 kW GMR™ 18 HD+ dome radar is available as a bundled option with your GPSMAP chartplotter/sonar package.





FEATURES:

  • Easily integrate with more engines.
  • Connect to compatible third-party devices with OneHelm™ digital switching.
  • Easily build your marine system using the best of network connectivity.
  • Navigate any waters with preloaded Garmin Navionics+™ charts and mapping1.
  • See below your boat with built-in sonar capabilities.
  • Manage your marine experience from nearly anywhere2.

Physical & Performance

Display Size

6.1" x 3.5"; 7.0" diagonal

(15.4 x 9.1 cm; 17.8 cm diagonal)
Power Input 10 to 32 Vdc
Display Resolution 1024 x 600 pixels
GPS Yes
Dimension 7.6" x 5.5" x 2.9" (19.2 x 14.0 x 7.4 cm)
Receiver

10 Hz
Waterproof IPX7
Weight

2.8 lbs (1.3 kg)
Mounting Options Bail, flush or flat (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.)
Display Type WSVGA

Maps & Navigation

Garmin Navionics Vision+™ Yes
Accepts Data Cards

2 microSD cards (back of unit)
Garmin Navionics+ Inland & Coastal Yes
Navigation Routes 100
Garmin Navionics+™ Yes

Features

Waypoints 5,000
Sailing Features Yes
NMEA 0183 Compatible Yes
Has built-in receiver Yes
USB ports Yes
TOPO Yes
SideVü built-in 260/455/800/1000/1200 kHz
DSC Yes
Touchscreen Yes
LakeVü g3 Ultra No
NMEA 2000 Compatible Yes
ActiveCaptain Mobile Planning Compatible

yes
Typical current draw at 12 Vdc 1.18 A
NMEA 2000 ports 1
Tide tables Yes
GLONASS Yes
Track points 50,000
Panoptix™ sonar Yes
Garmin Marine Network Ports

1
LakeVü g3 No
Supports WAAS Yes
GSD Black Box Sonar Support Yes
Maximum current draw at 12 Vdc 2.96 A
Smart Mode Compatible Yes
Built-in Auto Guidance No
Maximum power usage at 10 Vdc 35.9W
BlueChart g3 No
Standard Mapping Yes
LakeVu (inland) No
Built-in Auto Guidance+ Yes
Displays sonar Yes
ANT+ (Connectivity) Yes
GCV Black Box Sonar Support Yes
BNC external GPS antenna port Yes
Connections NMEA0183 Input Ports

1
Spoken audio alerts Yes
BlueChart g3 Vision No
Garmin Wi-Fi network (local connection) Yes
J1939 ports 1
Input Touchscreen
Garmin Quickdraw Contours Yes
BLUETOOTH® pairing Yes
AIS Yes
Raster chart support Yes
NMEA 0183 input (Tx) ports 1
OneHelm support Yes
ClearVü built-in 260/455/800/1000/1200 kHz
Tracks 50 saved tracks
Wireless Remote Compatible Yes
Supports Fusion-Link™ compatible radios Yes
Galileo Yes
LiveScope Yes
Power output 1 kW
12-pin transducer ports 1
BlueChart (coastal) No
Traditional sonar (dual frequency/beam) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
GRID (Garmin Remote Input Device) compatible Yes
Video input ports

1 (BNC composite)
SKU GAR.010-02365-62
Model # 010-02365-62
UPC/EAN 753759285319
Brand Garmin
Shipping Weight 3.3600kg
Shipping Width 0.190m
Shipping Height 0.070m
Shipping Length 0.130m
Shipping Cubic 0.001729000m3
Unit Of Measure ea
