Reliable 24V Lithium Power for Demanding Applications

Built for 24V energy storage applications requiring long service life, reduced weight and advanced battery management, this lithium battery combines LiFePO4 chemistry with an integrated BMS for safe and stable operation. Its 100Ah capacity provides substantial stored energy while offering significantly greater cycle life and lower weight than comparable SLA battery technology. Integrated protection manages overcharge, over-discharge, temperature and short-circuit conditions, while Bluetooth and CAN/RS485 communication provide flexible options for battery monitoring and integration with compatible equipment. The IP67-rated enclosure provides protection against demanding environmental conditions, while flexible battery bank configuration allows multiple batteries to be combined for increased system capacity. These characteristics support marine, recreational, mobile and off-grid power installations where dependable 24V energy storage, monitoring and system flexibility are required.

Key Features

• Long Cycle Life: Delivers more than 3,000 cycles at 100% depth of discharge, providing up to 10 times the cycle life of SLA battery technology.
• Integrated Battery Management: Built-in BMS provides protection against overcharge, over-discharge, temperature and short-circuit conditions.
• LiFePO4 Chemistry: Safe and stable lithium iron phosphate chemistry supports reliable operation and extended service life.
• Bluetooth Monitoring: Integrated Bluetooth connectivity enables battery monitoring through the INVICTA app.
• CAN/RS485 Communication: Wired communication capabilities provide additional options for connection with compatible devices and power systems.
• High Energy Density: Weighs less than half that of comparable SLA battery technology, helping reduce overall installation weight.
• IP67 Protection: Sealed construction provides protection against demanding environmental conditions.
• Flexible Battery Configuration: Supports expanded battery bank configurations, with the datasheet specifying up to 16 batteries in parallel and also noting configurations of up to 4 in series and 4 in parallel.
• High Discharge Capability: Supports a maximum continuous discharge current of 120A and pulse discharge current of up to 500A for 3 seconds.
• IEC 62619 Certification: Certified to IEC 62619 for lithium secondary cells and batteries used in industrial applications.

Combining long cycle life, integrated protection and multiple communication options, the battery supports flexible integration into a wide range of 24V electrical systems. Its sealed construction and reduced weight further support installations where space, durability and system monitoring are important considerations.
