Integrated trim tab control with LED position feedback

Manage a single-actuator trim tab system from a compact helm-mounted keypad with integrated control electronics and clear position feedback. Two high-intensity LED displays continuously indicate trim tab position, while built-in auto retract returns the tabs when power is removed. Waterproof Deutsch connectors, a backlit keypad and automatic light sensing support reliable and convenient operation in marine environments.

Key Features

• Single actuator compatibility: Suits Lenco trim tab plate kits with one actuator per plate.
• LED position indication: Two high-intensity LED displays provide continuous visual feedback of trim tab position.
• Built-in auto retract: Automatically retracts the trim tabs from their current position when power is removed.
• Integrated control box: Combines the keypad and control electronics into a compact all-in-one configuration.
• Instant response: Provides immediate trim tab actuation from the helm controls.
• Waterproof connections: Self-contained keypad incorporates waterproof Plug & Play Deutsch connectors.
• Automatic light adjustment: Integrated photo eye optimises LED visibility according to surrounding light conditions.
• Backlit keypad: Improves control visibility during nighttime and low-light operation.
• Self-check function: Performs a system check at power-up and uses the LED displays to indicate actuator connection faults.
• Low-profile mounting: Compact keypad requires a 52.4 mm cutout for a neat helm installation.
• 12 V / 24 V operation: Compatible with both 12 V and 24 V onboard electrical systems.
• 2.25-inch actuator compatibility: Specifically suited to Lenco actuators with a 2.25-inch stroke.

Integrated position indication makes it easier to monitor and adjust trim tab deployment directly from the helm. The compact all-in-one configuration combines control, feedback and auto-retract functionality while minimising installation complexity.
