Noark SHT22 24VDC Shunt Trip Release for MCCBs Ex9M Frame M2 and M3

The Noark SHT22 24VDC Shunt Trip Release is a crucial component designed for use with moulded case circuit breakers (MCCBs) in the Ex9M series, specifically for Frame M2 and M3. This device is essential in electrical systems for enabling remote tripping of the circuit breaker, enhancing both the functionality and safety of the system.

Key Features and Characteristics:

  • Compatibility: Specifically suitable for power circuit breakers, enhancing their operational safety and reliability.
  • Rated Control Supply Voltage: Operates effectively with a control supply voltage of 24V DC, ensuring consistent performance and responsiveness.
  • Electric Connection Type: Designed with a unique type of electric connection to ensure secure and efficient integration with the circuit breaker.
  • Voltage Type for Actuating: Utilizes DC voltage for actuating, providing a stable and reliable trigger mechanism.
  • Versatile Use: Suitable for use in off-load switches, broadening its application range in electrical systems.
  • Excluded Applications: Not suitable for motor safety switches or overload relays, focusing its functionality on circuit breaker tripping.

The Noark SHT22 Shunt Trip Release is an integral part of modern electrical safety mechanisms, providing reliable and efficient remote tripping capabilities. It's designed to ensure the safe and controlled operation of circuit breakers in various industrial and commercial settings.

Specification Detail
Suitable for Power Circuit Breaker Yes
Rated Control Supply Voltage Us at DC 24V
Type of Electric Connection Other
Voltage Type for Actuating DC
Suitable for Off-Load Switch Yes
Suitable for Motor Safety Switch No
Suitable for Overload Relay No
SKU NRK.N23179
Model # 23179
Brand Noark
Shipping Weight 0.1200kg
