Advanced omni-directional antenna delivering reliable marine and coastal connectivity

This omni-directional antenna uses a combination of low-gain and high-gain radiating elements to maintain stable pattern control across all supported frequencies, ensuring dependable 4×4 MIMO performance in marine and coastal environments. Its ultra-wideband capability supports a broad range of LTE and 5G bands, while the rugged IP68 fiberglass construction provides full protection against saltwater, dust and severe offshore weather exposure.

Key Features

  • Hybrid gain architecture: Integrates low-gain and high-gain omni elements for balanced pattern consistency.
  • 4×4 MIMO capability: Enhances stability, throughput and multi-stream performance across supported networks.
  • Ultra-wideband frequency support: Operates from 617–4200 MHz, including Band 71 and CBRS frequencies.
  • True omni-directional coverage: Maintains uniform 360° performance suitable for maritime installations.
  • IP68 marine-grade durability: Fully sealed design protects against heavy storms, water ingress and dust.
  • Fiberglass radome construction: Offers long-term resistance to saltwater and corrosive coastal conditions.
  • Global deployment compatibility: Performs reliably in worldwide inland and offshore communication systems.
  • Optional bracket support: Compatible with 316 stainless steel mounting hardware for enhanced stability.

Built for demanding offshore conditions, this antenna provides strong, consistent coverage and long-lasting protection for marine and coastal wireless installations.

Specification Description
Industry (Application) Marine & Coastal Antennas
Technology Cellular (LTE/2G/3G/4G/CBRS/5G)
Frequency Band 617-698MHz, 698-803MHz, 791-894MHz, 868-915MHz, 880-960MHz, 1427-1517MHz, 1700-1900MHz, 1900-2200MHz, 2300-2400MHz, 2400-2500MHz, 2500-2700MHz, 3400-3800MHz, 3800-4200MHz
Frequency Range 617 – 4200 MHz
Gain 3dBi, 8dBi
5G Bands n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n48, n51, n53, n65, n66, n67, n71, n74, n75, n76, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n106, n256
Directionality Omni-Directional
LTE/4G Bands B1, B2, B3, B4, B5, B7, B8, B9, B10, B12, B13, B14, B17, B18, B19, B20, B25, B26, B27, B28, B29, B30, B33, B34, B35, B36, B37, B38, B39, B40, B41, B44, B53, B65, B66, B67, B68, B69, B71, B74, B85, B103, B106
Mounting Type Marine Mount
Wi-Fi Standard Wi-Fi 3 (802.11g)
Connectors N-Type
MIMO 4×4
Polarisation Linear Polarised
Environmental IP68, Marine Grade, Salt Spray Protected
Enclosure Name Narwhal
Enclosure Size Large
LTE Ports 4
SKU POY.OMNI-904
Model # A-OMNI-0904-V1-01
Brand Poynting
Shipping Weight 8.0000kg
Shipping Width 1.750m
Shipping Height 0.230m
Shipping Length 0.440m
Shipping Cubic 0.177100000m3
Unit Of Measure Each
