High-Performance Wideband Antenna for 4G and 5G Connectivity

The XPOL-1-5G+ is Poynting’s third-generation cross-polarised MIMO antenna, redesigned with a new enclosure and advanced elements for superior performance. Covering ultra-wideband frequencies from 410 to 6000 MHz, it supports multiple operators and technologies, making it ready for current and future 5G applications. With peak gains up to 7 dBi, omni-directional coverage, and a robust IP65 housing, it provides reliable, high-speed connectivity for fixed wireless access, small businesses, and mobile deployments.

Key Features

  • Ultra-wideband coverage: Operates from 410 MHz to 6000 MHz, supporting 4G LTE and 5G.
  • High-gain performance: Delivers up to 7 dBi peak gain for improved signal and coverage.
  • Cross-polarised MIMO design: 4×4 MIMO with +45°, -45°, vertical, and horizontal polarisation for enhanced throughput.
  • Omni-directional radiation: Ensures wide-area coverage with consistent performance across bands.
  • Durable enclosure: Weather, dust, and vandal resistant with IP65 protection.
  • Flexible installation: Wall, pole, and window mounting options included.
  • Built for harsh conditions: Wind survival up to 250 km/h, UV-stable radome, and operating range of -40 °C to +80 °C.

This antenna is ideal for fixed wireless access, home and office connectivity, and as a backup option for fibre or Starlink installations, ensuring dependable broadband access in all environments.

Product Specifications
Frequency Range 410 – 6000 MHz
Polarisation Cross Polarised (+45°, -45°, Vertical, Horizontal)
Gain -4 dBi @ 410–470 MHz; 1.5 dBi @ 617–960 MHz; 2 dBi @ 1427–1517 MHz; 6 dBi @ 1710–2700 MHz; 7 dBi @ 3300–4200 MHz; 5 dBi @ 4400–6000 MHz
Peak Gain 7 dBi
VSWR ≤2.5:1 across 90% of bands
MIMO Support 4x4 MIMO
Connector Type SMA Male (factory mounted)
Cable Type & Length HDF 195, 5 m
Input Impedance 50 Ohm
Max Input Power 10 W
Ingress Protection IP65
Dimensions (mm) 246 × 157 × 88 (including bracket)
Weight 1.05 kg (1.45 kg packaged)
Mounting Options Pole, wall, or window mount
Wind Survival ≤250 km/h
Operating Temperature -40 °C to +80 °C
Environmental Resistance UV-stable ASA radome, IK10 impact rating, UL 94-HB flammability
Compliance CE, RoHS, ISO 9001:2015
SKU POY.XPOL-1-PLUS
Model # A-XPOL-0001-V3-41
Brand Poynting
Shipping Weight 2.0000kg
Shipping Width 0.270m
Shipping Height 0.120m
Shipping Length 0.190m
Shipping Cubic 0.006156000m3
Unit Of Measure Each
