Ultra High-capacity Hybrid Inverter for Demanding Three Phase Systems

The Pylontech Force H3X 12kW Three Phase Hybrid Inverter is purpose-built for large residential and commercial solar energy applications. With exceptional efficiency, scalable storage integration, and robust safety features, it delivers reliable performance for advanced solar and battery installations.

Key Features

  • Large output capacity: Supplies 12kW nominal power, ideal for heavy-duty residential and business loads.
  • Superior efficiency: Operates with a maximum efficiency of 97.6%, reducing energy waste.
  • Three phase architecture: Ensures balanced three phase distribution for stable and reliable operation.
  • Battery system compatibility: Designed for seamless use with Pylontech Force-H3X battery systems.
  • Flexible energy modes: Operates in grid-tied, off-grid, and backup power scenarios.
  • Advanced communication: RS485 and CAN interfaces, with optional Wi-Fi for monitoring and control.
  • Comprehensive safety: Features over-voltage, over-current, short circuit, and thermal protection.
  • Rugged outdoor design: IP65-rated enclosure for durability in varied environments.
  • 12-month warranty: Covered by a one-year manufacturer’s warranty for peace of mind.

This inverter provides unmatched performance for larger energy systems, ensuring stability, efficiency, and long-term reliability.

Product Specifications
Nominal Power 12000 W
Nominal AC Voltage 400 V
Nominal AC Frequency 50 Hz / 60 Hz
Max Efficiency 97.6%
MPPT Voltage Range 125 – 500 V
Max PV Input Voltage 600 V
Max Input Current 26 A + 26 A
Battery Voltage Range 100 – 600 V
Communication Interfaces RS485, CAN, Wi-Fi (optional)
Protection Rating IP65
Operating Temperature -25°C to +60°C
Dimensions (W × H × D) 550 × 516 × 191 mm
Weight 28 kg
SKU PYL.FH3X-12K-HY-3P
Model # FH3X-12K-HY-3P
Brand Pylontech
Shipping Weight 32.0000kg
Unit Of Measure ea
