Raymarine RVM1600: Advanced CHIRP Sonar Module

The Raymarine RVM1600 revolutionizes the fish-finding experience for anglers with its advanced CHIRP sonar module, integrating RealVision MAX and 1kW broadband CHIRP technologies. Designed for compatibility with Axiom chartplotters, this device takes multi-channel fish finder performance to unprecedented depths, offering unparalleled clarity and range.

Key Features:

  • High-Performance CHIRP Transducers: Upgraded elements with increased power output extend fish finder range and performance.
  • RealVision MAX CHIRP Processing: Enhanced signal processing and faster ping rates for improved imagery and target identification.
  • High-Contrast Color Palettes: Fish and structures are easily distinguishable with refined color palettes designed to accentuate targets.
  • Deep Range Performance: Track the bottom in depths greater than 1,200' (366 meters) and locate fish beyond 400' (123 meters).

Multi-Channel Sonar Capabilities:

  • CHIRP DownVision: Delivers a photo-like view of the underwater environment.
  • CHIRP SideVision: Provides extensive coverage of fish, bait, and structures on both port and starboard sides.
  • RealVision MAX 3D: Offers a comprehensive view of the underwater world, making it easier to locate and track fish.

RealVision MAX Transducers:

  • Versatile Mounting: Options for transom mount and through-hull installations.
  • Built-in AHRS: Stabilizes 3D sonar imagery and compensates for vessel motion.
  • Fast-Response Temperature Sensor: Offers accurate sea temperature readings.

Designed for serious anglers, the Raymarine RVM1600 is a game-changer in marine sonar technology, providing an unmatched fish-finding experience with clarity and range that's second to none.

Technical Specifications:

Feature Specification
Sonar Type CHIRP DownVision, SideVision, High CHIRP, 3D
Maximum Depth > 1,200' (366 meters)
Frequency High CHIRP (600-watt)
Transducer Compatibility RealVision MAX Transom Mount and Through Hull
Display Compatibility Axiom Chartplotters
Additional Features Built-in AHRS, Temperature Sensor
Environmental
Relative humidity up to 93% @ 40 °C (104 °F)
Waterproof rating IPx6, IPx7
Non-operating temperature -30 °C (-22 °F) to +70 °C (158 °F)
Operating temperature -25 °C (-13 °F) to +55 °C (131 °F)
Sonar
Power output RealVision MAX high CHIRP sonar channel: 600 Watts RMS Traditional dual channel CHIRP channel: 1kW RMS
Sonar channels RealVision MAX Port: High CHIRP (200kHz), DownVision (350kHz), SideVision (350kHz) and RealVision 3D (350kHz) 1kW CHIRP Port: 42 - 250kHz (Transducer dependent)
Connections 1x 3-pin Male power connector, 1x 10-pin RayNet network connector, 1x 25-pin RealVision Max 3D / RealVision 3D transducer connector, 1x 11-pin 1kW transducer connector
Conformance
Product markings UKCA, CE, Australian RCM C-Tick, RoHS, WEEE Directive
Standards EMC Directive 2014/30/EU, RoHS II 2011/65/EU, Worldwide Safety EN/IEC 62368-1, Europe, UK, Australia, New Zealand: EN/IEC 60945:2002, Australia and New Zealand: C-Tick, Compliance Level 2, Canada: ICES-003 (exempt when factory installed in a transport vehicle), USA: CFR47 Part 15b (SDoC exempt, installed in transport vehicle), Japan / China: ABS/CCS IEC 60945:2002, FCC Part 15.19, FCC Part 15.105 (b), ISEDC ICES-003
Physical
Depth 84.4 mm (3.32 in)
Width 299.4 mm (11.79 in)
Height (including cable bend radius) 285.6 mm (11.24 in)
Height (including connectors) 205.6 mm (8.09 in)
Height 188.0 mm (7.40 in)
Weight 1.585 kg (3.49 lbs)
Power
Inline fuse rating 5 A
Thermal breaker rating 5 A
Current 2.4 A Peak; 1.2 A RMS (Maximum) @ 12 V dc
Nominal supply voltage 12 V / 24 V dc
Operating voltage range 10.8 V to 31.2 V dc
Power consumption 10.4 W (Maximum)
SKU RAY.E70665
Model # E70665
Brand Raymarine
Shipping Weight 2.6000kg
Shipping Width 0.084m
Shipping Height 0.188m
Shipping Length 0.299m
Shipping Cubic 0.004722000m3
Unit Of Measure ea
