High-Efficiency Charger with Wireless Monitoring and Adaptive Algorithm

Designed for advanced battery care, this intelligent charger features Bluetooth connectivity and a six-stage adaptive charge algorithm. With up to 94% efficiency, it reduces heat generation and power consumption, making it suitable for both workshop and mobile use. It supports lead-acid and lithium batteries and can recover fully discharged units, including Li-ion types with internal disconnect. Programmable via app, the charger also supports VE.Smart networking for synchronised parallel charging across multiple units.

Key Features

  • Bluetooth Smart Connectivity: Enables wireless configuration, monitoring, firmware updates and charge history review via the VictronConnect app.
  • High Efficiency Performance: Operates at up to 94% efficiency with minimal heat and just 0.5W standby consumption.
  • Adaptive 6-Stage Charging: Automatically optimises charge stages—Test, Bulk, Absorption, Recondition, Float, Storage—based on battery usage.
  • Fully Programmable Algorithm: Allows adjustment of all voltage levels and time limits via app, including Expert Mode settings.
  • Storage Mode for Battery Longevity: Reduces voltage after 24 hours of inactivity to limit corrosion and sulphation, with weekly equalisation.
  • Lithium Battery Compatible: Supports Li-ion batteries using a simplified bulk–absorption–float profile.
  • Discharged Battery Recovery: Capable of initiating charge on batteries drained to zero volts, including Li-ion with internal disconnects.
  • Silent Operation Modes: NIGHT and LOW modes reduce output to 50% and operate completely silently—ideal for noise-sensitive environments.
  • Overheat Protection: Automatically reduces output current with rising temperature, remaining functional up to 50°C.
  • Visual Status Display: Eleven LEDs indicate precise charge stage; physical MODE button for quick selection of normal, high, recondition or Li-ion modes.
  • Charge History Logging: Tracks detailed statistics for the last 40 charge cycles for maintenance or troubleshooting.
  • VE.Smart Network Support: Enables smart sensor communication and synchronised parallel charging with up to 10 compatible chargers.
  • Robust Construction: IP22-rated aluminium enclosure with wide operating temperature and high humidity tolerance.

Optimised for reliability, versatility and long-term battery health, this charger is ideal for both mobile and fixed installations.

Product Specifications
Input Voltage Range 180 – 265 VAC
Frequency 45 – 65 Hz
Output Voltage 12 V or 24 V models available
Charge Current (Normal) Up to 30 A (12 V) / 16 A (24 V)
Charge Current (Night/Low) Up to 15 A (12 V) / 8 A (24 V)
Efficiency Up to 94%
No Load Consumption 0.5 W
Charge Algorithm 6-stage adaptive
Battery Types Supported Lead-acid (AGM/GEL), Li-ion
Output Channels 1 or 3
Protection Features Reverse polarity, short circuit, over temperature
Operating Temperature -40 to +60 °C (rated output to 40 °C)
Humidity Max 98% (non-condensing)
Enclosure Material Aluminium (RAL 5012 blue)
Ingress Protection IP22
Dimensions (H × W × D) 235 × 108 × 65 mm
Weight 1.3 kg
AC Input Cable 1.5 m with AU/NZ, UK or EU plug
Battery Terminals Screw terminals (16 mm² / AWG6)
Standards Compliance EN 60335, EN 55014, ECE R10-5
SKU VIC.BPC241647012
Model # BPC241647012
UPC/EAN 8719076052487
Brand Victron Energy
Shipping Weight 1.5500kg
Shipping Width 0.260m
Shipping Height 0.070m
Shipping Length 0.160m
Shipping Cubic 0.002912000m3
Unit Of Measure ea

Purchase with confidence knowing your product is covered by the Victron 5-year manufacturer warranty.
