Smart 12 V Inverter for Marine, RV and Off-Grid Power Systems

The Victron Inverter Smart 12/2500 converts power from a 12 V battery system into a stable 230 V AC supply for marine, RV, caravan, off-grid and mobile installations. Built-in Bluetooth provides wireless access to inverter settings and operating information from a compatible smartphone or tablet, while the VE.Direct communication port supports connection to compatible Victron monitoring equipment. Configurable operating parameters include battery voltage alarms, low-voltage cut-off and restart levels, output voltage, frequency and ECO mode settings. High start-up power supports loads with increased initial power requirements, while remote on/off control and a programmable relay provide additional options for integration into complete power systems.

Key Features

• Built-In Bluetooth: Enables wireless configuration and monitoring using a compatible smartphone or tablet.
• VE.Direct Connectivity: Supports connection to compatible Victron monitoring and system integration equipment.
• Configurable Battery Protection: Low battery alarm, cut-off and restart levels can be adjusted to suit the installation.
• Dynamic Low-Voltage Cut-Off: Load-dependent DC shutdown helps manage operation as battery voltage changes under load.
• High Start-Up Capability: Accommodates equipment requiring increased power during start-up.
• ECO Mode: Automatically switches to standby when the connected load falls below a configured threshold and resumes operation when demand increases.
• Remote On/Off: Supports control through an external switch or relay contact.
• Programmable Relay: Can be configured for general alarms, DC undervoltage or generator start/stop functions.
• Integrated Electrical Protection: Covers output short circuit, overload, excessive battery voltage, low battery voltage, excessive temperature, AC voltage on the inverter output and excessive input voltage ripple.
• Steel Enclosure: Robust steel housing with fan-assisted cooling and IP21 protection.
• System Monitoring: Supports monitoring of input voltage, output voltage, connected load and inverter alarms.

Bluetooth configuration, VE.Direct communication and remote control capabilities allow the inverter to integrate with a broader battery and energy monitoring system. Its configurable protection and ECO functions also provide greater control over operation in battery-powered installations.
