Victron MultiPlus 48/20k/250-100 230V
High-capacity inverter charger offering 20 kVA output with 250 A charging, PowerAssist, ESS compatibility, and advanced GX monitoring for reliable off-grid or hybrid power.
SKU: VIC.PMC483200400 | MPN: PMC483200400
SAVE $1,732.21 (29%)
Available at Victron
In Stock at Victrons Australian warehouse and typically ships within 5-6 Business Days.
High-capacity inverter charger delivering powerful and efficient energy management
The MultiPlus 48/20k/250-100 230 V delivers exceptional 20 kVA power for advanced off-grid, marine, and commercial energy systems. It combines a high-performance inverter and intelligent charger in one robust enclosure, providing seamless power continuity, grid-assist capability, and full system integration with Victron GX monitoring platforms. Designed for demanding installations, it ensures stable operation even under high surge loads and heavy-duty charging conditions.
Key Features
- High-power inverter: Provides 20 kVA continuous output with pure sine wave for efficient and stable energy delivery across critical and auxiliary loads.
- Advanced PowerAssist technology: Automatically supplements generator or grid supply with battery power during demand peaks, ensuring no interruptions to connected systems.
- Dual AC outputs: Supplies uninterrupted power to priority circuits while isolating non-essential loads when off-grid or during generator disconnection.
- Parallel and three-phase scalability: Supports up to six parallel units or three-phase configurations for multi-unit systems exceeding 120 kVA capacity.
- Intelligent adaptive charging: 250 A charger with temperature-compensated, multi-stage control ensures optimal performance for lithium and lead-acid batteries.
- Full ESS compatibility: Integrated anti-islanding function and certified compliance for energy storage system applications in grid-connected or off-grid setups.
- Comprehensive monitoring: Compatible with Cerbo GX, Ekrano GX, and the VRM portal for local or remote configuration, data logging, and live performance analysis.
- High surge capability: Handles up to 36 kW peak power to start inductive loads and manage instantaneous current surges.
- Efficient thermal design: Operates between –20 °C and +65 °C with fan-assisted cooling for reliable performance in demanding environments.
- Robust build quality: Steel enclosure with IP21 protection and heavy-duty M8 terminals ensures long service life in professional and industrial settings.
Built for large-scale off-grid and hybrid systems, it provides uncompromising performance, intelligent control, and seamless energy autonomy across all applications.
| Technical Specifications | |
|---|---|
| Nominal Battery Voltage | 48 V |
| Continuous Output Power at 25 °C | 20 000 VA / 16 000 W |
| Continuous Output Power at 40 °C | 14 000 W |
| Continuous Output Power at 65 °C | 10 000 W |
| Peak Power | 36 000 W |
| AC Output Voltage | 230 V ± 2 % |
| AC Output Frequency | 50 Hz ± 0.1 % |
| DC Input Voltage Range | 38 – 66 V DC |
| Maximum Battery Charge Current | 250 A |
| AC Input Voltage Range | 230 V ± 10 % |
| Maximum AC Input Current | 100 A |
| Transfer Switch | 100 A |
| Charger Efficiency | Up to 96 % |
| Zero Load Power | 60 W |
| Zero Load Power (AES Mode) | 42 W |
| Zero Load Power (Search Mode) | 8 W |
| Operating Temperature Range | –20 °C to +65 °C (fan assisted) |
| Communication Ports | VE.Bus, VE.Can, VE.Direct, USB, Ethernet |
| Protection Features | Short circuit, overload, over/undervoltage, overtemperature, AC feedback, input ripple |
| Compatible Battery Types | Lead-acid, Lithium, Zinc-Bromine, custom chemistries |
| Auxiliary AC Output | Yes (50 A) |
| Enclosure Material | Steel – Blue RAL 5012 |
| Protection Category | IP21 |
| Dimensions (H × W × D) | 870 × 430 × 220 mm |
| Weight | 92 kg |
| Compliance Standards | EN-IEC 60335-1, EN-IEC 62109-1/2, AS/NZS 4777.2:2020 + A1/A2 |
| SKU | VIC.PMC483200400 |
| Model # | PMC483200400 |
| UPC/EAN | 8719076068358 |
| Brand | Victron Energy |
| Shipping Weight | 78.0000kg |
| Shipping Width | 0.620m |
| Shipping Height | 0.550m |
| Shipping Length | 0.750m |
| Shipping Cubic | 0.255750000m3 |
| Unit Of Measure | ea |
