Alta Labs 24-Port Enterprise Network Switch, Layer 2, 240W PoE

The Alta Labs 24-Port Enterprise Network Switch stands as a beacon of network performance and efficiency, tailored for the sophisticated needs of modern enterprises. Boasting Layer 2 functionality and an impressive 240W Power over Ethernet (PoE) support, this enterprise-grade switch is engineered to streamline connectivity, enhance security, and facilitate efficient data management across your organization's network infrastructure.

Key Features:

  • Layer 2 Functionality: Delivers advanced networking capabilities, enabling more efficient data packet routing, improved traffic management, and reduced congestion across the network.
  • 240W Power over Ethernet (PoE): Offers robust PoE support, efficiently powering up PoE-enabled devices directly through the network cables, thus simplifying the network infrastructure and reducing cable clutter.
  • High-Performance Networking: This switch is designed to handle the demands of enterprise environments, ensuring high-speed data transfer, minimal latency, and reliable connectivity for all networked devices.
  • Scalable Network Design: With 24 gigabit Ethernet ports, it provides ample capacity for connecting a wide array of devices, from servers and storage arrays to wireless APs and IP cameras, facilitating network growth and expansion.
  • Advanced Security Features: Incorporates comprehensive security measures including VLAN segmentation, Access Control Lists (ACLs), and port security to protect sensitive data and guard against unauthorized access.
  • Effortless Network Management: Equipped with an intuitive web interface, this switch allows for easy setup, configuration, and management of network settings, VLANs, and QoS policies, enhancing overall network efficiency and control.

Enhanced Network Efficiency and Security:

The Alta Labs 24-Port Switch is not just about connectivity; it's about providing a secure, manageable, and efficient networking foundation. It's designed to meet the rigorous demands of enterprise operations, offering features that ensure optimal performance and security.

General Specifications:

Specification Detail
Total Ethernet Ports 24 Gigabit Ethernet Ports
PoE Support 240W Total PoE Budget
Layer Support Layer 2 Switching
Security Features VLANs, ACLs, MAC-based Port Security
Management Interface Web-Based Management
Switching Capacity High Capacity for Seamless Data Transfer
Power Efficiency Energy-Efficient with IEEE 802.3az Support

This switch is the cornerstone of a modern network infrastructure, providing the tools and capabilities needed to support complex network architectures, ensure secure data transmission, and enable efficient management of network resources

Specification S16-POE S24-POE
Total Ports 16 24
PoE Ports 8 16
Uplink Ports 2 SFP 2 SFP+
Power Budget 120 W 240 W
Interface Ports Speed 10/100/1000 Mbps 10/100/1000 Mbps
Switching Capacity 36 Gbps 88 Gbps
Non-blocking Throughput 18 Gbps 44 Gbps
Forwarding Rate 26.8 Gbps 65.5 Gbps
PoE Budget/Max 120 Watts 240 Watts
PoE Supply per Port 30 Watts 30 Watts
Per Port PoE (8) 802.3at PoE+ (16) 802.3at PoE+
Non-PoE Ports 8 8
PoE Indicator Orange Orange
Network Speed Indicator Orange: 10/100 Mbps, Blue: 1000Mbps Orange: 10/100 Mbps, Blue: 1000Mbps
SFP/SFP+ Indicator Blue - Link/Activity (1000 Mbps) Blue - Link/Activity (1000 Mbps, 2500 Mbps, 5000Mbps), White - Link/Activity (10 Gbps)
Packet Buffer 4.1Mbit 12Mbit
MAC Table Size 8K 16K
Energy Efficient Ethernet Yes Yes
Management Factory reset button Factory reset button
Dimensions 44mm x 254 mm x 441.5 mm 44mm x 254 mm x 441.5 mm
Material Type SGCC SGCC
Material Finish Powder coat - Matte Powder coat - Matte
Color Metallic gray Metallic gray
Mounting Options Rack mount Rack mount
Operating Temperature -5 to 50° C -5 to 50° C
Operating Humidity 10 - 90% Non-condensing 10 - 90% Non-condensing
IP Rating None None
EMI Rating EMI Class-A with 3dB margin EMI Class-A with 3dB margin
Cooling Fan None Yes
Chipset Realtek Realtek
Bluetooth Yes - Setup Yes - Setup
Power Consumption w/o PoE 23 Watts 53 Watts
Power Consumption Full PoE 143 Watts 295 Watts
Power Supply Universal AC, 100-240VAC 50/60Hz Internal Universal AC, 100-240VAC 50/60Hz Internal
RJ45 Port Surge Protection 12kV for ESD - contact, 25kV for ESD - Air 12kV for ESD - contact, 25kV for ESD - Air
Certifications FCC, CE, IC FCC, CE, IC
SKU ALT.S24-POE
Model # S24-POE
Brand Alta Labs
Shipping Weight 3.6000kg
Shipping Width 0.044m
Shipping Height 0.442m
Shipping Length 0.254m
Shipping Cubic 0.004940000m3
