FREEDOM OF CHOICE TO LISTEN TO WHAT YOU WANT
Take advantage of the many source options available, including Bluetooth® technology, DAB+ radio, AM/FM radio, AUX and USB connections.
General |
|
DIMENSION | 7.4" x 2.36" x 4.87" (188 x 60 x 123.5 mm) |
---|---|
DISPLAY | 2.6" optically bonded monochrome LCD |
WEIGHT |
1.23 lbs (556 g) |
WATER RATING | IPX7 (front panel only, when properly installed) |
OPERATING TEMPERATURE | 32° to 122° F (0° to 50° C) |
CURRENT (MAX) | 15 A |
Networking |
|
NMEA 2000® LEN | see Additional |
---|---|
BLUETOOTH® WIRELESS RANGE | up to 30 ft (10 meters) |
ANT® WIRELESS RANGE | Up to 10 ft (3 meters) |
WIRELESS FREQUENCIES/PROTOCOLS | BLUETOOTH®: 2.4 GHz @ +1.9 dBm nominal ANT®: 2.4 GHz @ +1.9 dBm nominal |
Audio |
|
AMPLIFIER | Class-AB (4 ohm) |
---|
Stereo Features |
|
PEAK POWER | 200 watts |
---|---|
RATED POWER OUTPUT (4 OHM) | 26 watts RMS x 4 @ 14.4 V input < 10% THD |
FUSION-LINK™ CONTROL | Yes (see Additional) |
MULTI-ZONE™ TECHNOLOGY | 2 zones |
BLUETOOTH® WIRELESS TECHNOLOGY | |
ANT® WIRELESS TECHNOLOGY | |
SIRIUSXM-READY | see Additional |
DAB+ READY | see Additional |
SUPPORTS NRX WIRED REMOTE | see Additional |
MULTI-LANGUAGE INTERFACE | Dutch, English, French, German, Italian, Spanish |
SOFTWARE UPDATES | USB |
WARRANTY | 1 year |
Sources |
|
SUPPORTED SOURCES |
AM, FM, BLUETOOTH®, USB audio, iPhone®, iPod®, AUX x1, AOA MS-RA70NSX: SiriusXM-Ready (U.S. only, requires optional SiriusXM Connect vehicle tuner) MS-RA70 and MS-RA70N: DAB+ ready (available in Europe and Australia only) |
---|
Connections |
|
AUXILIARY INPUTS (RCA) | 1 |
---|---|
NMEA 2000® PORTS | 1 (MS-RA70N and MS-RA70NSX only) |
USB 2.0 PORTS | 1 |
SIRIUSXM PORTS | 1 (MS-RA70NSX only) |
AM/FM PORTS (MOTOROLA ANTENNA CONNECTOR) | 1 |
SPEAKER CONNECTIONS | 4 (2 zone amplified) |
RCA PRE-OUT (LEFT, RIGHT AND SUBWOOFER) | 2 zones (requires external amplification) |
LINE OUT | 2 (L + R per zone, requires external amplification) |
SUBWOOFER OUT | Zone 1 (mono output, requires external amplification) |
Electrical features |
|
POWER INPUT | 10.8 - 16 VDC |
---|---|
COMPASS SAFE DISTANCE | 5.9" (150 mm) |
Additional |
|
ADDITIONAL |
NMEA 2000® LEN: 1 (50 mA), MS-RA70N and MS-RA70NSX only |
---|
General |
|
Physical dimensions (HxWxD) | 60 x 188 x 123.5 mm |
Weight | 556 g |
Water rating | IPX7 (front panel only, when properly installed) |
Power input | 10.8-16 VDC |
Operating temperature range | 0° to 50° C |
Current (max) | 15 A |
NMEA 2000 LEN | 1 (50 mA) |
Bluetooth wireless range | 10 metres |
ANT wireless range | 3 metres |
Wireless frequencies/protocols | Bluetooth 2.4 GHz @ +1.9 dBm nominal ANT 2.4 GHz @ +1.9 dBm nominal |
Compass-safe distance | 150 mm |
Stereo features |
|
Display | 128 x 64 optically bonded monochrome LCD |
Built-in amplifier | Class-AB |
Peak power | 200 W |
Rated power output (4 Ohm) | 26 W rms x 4 @ 14.4 V input < 10% THD |
Fusion-Link™ control | MS-RA70: Yes (smartphone and Garmin watch) MS-RA70N: Yes (MFD, smartphone and Garmin watch) |
Multi-Zone™ technology | 2 zones |
Bluetooth wireless technology | Yes |
ANT wireless technology | Yes |
DAB+ ready | MS-RA70 and MS-RA70N only; (requires DAB100A antenna module) |
NRX remote compatibility | MS-RA70N only |
Multi-language interface | Dutch / English / French / German / Italian / Spanish |
Fits DIN-sized cutout | Yes |
Software updates | USB |
Warranty | 3 year |
Sources |
|
Sources | AM / FM / Bluetooth / USB audio / iPhone / iPod / AUX x1 / AOA MS-RA70 and MS-RA70N only: DAB+ ready (available in Europe and Australia only) |
Connectivity |
|
Auxiliary input | One RCA input (AUX) |
NMEA 2000 | MS-RA70N : 1 port |
USB 2.0 | One USB 2.0 port |
AM/FM radio | One Motorola antenna connector port |
Speaker | 4 x speaker connections (2 zone amplified) |
RCA Pre-out (left, right and subwoofer) | 2 zones (requires external amplification) |
Line out | Zone 1, Zone 2 (L + R, requires external amplification) |
Subwoofer out | Zone 1, Zone 2 (requires external amplification) |
SKU | FUS.010-01516-11 |
Model # | 010-01516-11 |
UPC/EAN | 0753759149840 |
Brand | Fusion |
Shipping Weight | 1.2600kg |
