Reliable Hybrid Inverter Designed for Seamless Single Phase Energy Use

The Pylontech Force H3X 6kW Single Phase Hybrid Inverter is engineered to deliver efficient energy management for residential and small commercial applications. With advanced conversion efficiency, flexible operation modes, and robust protection systems, it ensures dependable integration of solar generation and battery storage.

Key Features

  • High conversion efficiency: Operates with up to 97.6% maximum efficiency to reduce losses.
  • Battery integration: Works seamlessly with Pylontech Force-H3X battery systems for energy storage.
  • Flexible application modes: Supports grid-tied, off-grid, and backup power functions.
  • Smart connectivity: Built-in RS485 and CAN with optional Wi-Fi for remote monitoring.
  • Robust protection: Equipped with multiple safety protections against over-voltage, short circuit, and overheating.
  • Compact and practical design: Streamlined build with clear interface for easy installation and use.
  • Quiet cooling system: Intelligent fan control minimises operating noise.
  • 12-month warranty: Covered by a one-year manufacturer’s warranty for assured reliability.

This inverter provides a dependable energy solution, delivering stability and efficiency for modern solar and storage systems.

Product Specifications
Nominal Power 6000 W
Nominal AC Voltage 230 V
Nominal AC Frequency 50 Hz / 60 Hz
Max Efficiency 97.6%
MPPT Voltage Range 125 – 500 V
Max PV Input Voltage 600 V
Max Input Current 18 A + 18 A
Battery Voltage Range 100 – 600 V
Communication Interfaces RS485, CAN, Wi-Fi (optional)
Protection Rating IP65
Operating Temperature -25°C to +60°C
Dimensions (W × H × D) 550 × 516 × 191 mm
Weight 28 kg
SKU PYL.FH3X-6K-HY-1P
Model # FH3X-6K-HY-1P
Brand Pylontech
Shipping Weight 32.0000kg
Unit Of Measure ea
