High-Power Hybrid Inverter for Advanced Single Phase Solar Systems

The Pylontech Force H3X 8kW Single Phase Hybrid Inverter is designed for larger residential and small commercial applications requiring robust energy management. Offering high conversion efficiency, wide battery compatibility, and multiple operation modes, it ensures seamless solar and storage integration with reliable performance under varying load conditions.

Key Features

  • High output capacity: Delivers 8kW nominal power, supporting greater household and commercial demands.
  • Superior efficiency: Achieves up to 97.6% maximum efficiency for minimal energy losses.
  • Battery integration: Works seamlessly with Pylontech Force-H3X storage systems.
  • Versatile operation: Functions in grid-tied, off-grid, and backup scenarios.
  • Advanced protection: Safeguards against over-voltage, short circuits, overheating, and over-current.
  • Smart connectivity: Features RS485 and CAN communication, with optional Wi-Fi for monitoring.
  • Durable construction: IP65-rated enclosure ensures reliable outdoor performance.
  • 12-month warranty: Covered by a one-year manufacturer’s warranty for dependable support.

This inverter delivers stable, efficient, and scalable power conversion, making it ideal for demanding solar energy applications.

Product Specifications
Nominal Power 8000 W
Nominal AC Voltage 230 V
Nominal AC Frequency 50 Hz / 60 Hz
Max Efficiency 97.6%
MPPT Voltage Range 125 – 500 V
Max PV Input Voltage 600 V
Max Input Current 22 A + 22 A
Battery Voltage Range 100 – 600 V
Communication Interfaces RS485, CAN, Wi-Fi (optional)
Protection Rating IP65
Operating Temperature -25°C to +60°C
Dimensions (W × H × D) 550 × 516 × 191 mm
Weight 28 kg
SKU PYL.FH3X-8K-HY-1P
Model # FH3X-8K-HY-1P
Brand Pylontech
Shipping Weight 32.0000kg
Unit Of Measure ea
