High-capacity Hybrid Inverter for Advanced Three Phase Solar Systems

The Pylontech Force H3X 10kW Three Phase Hybrid Inverter is engineered for residential and commercial installations requiring higher energy output and stability. With superior efficiency, wide battery compatibility, and advanced connectivity, it ensures seamless solar and storage integration for reliable three phase power management.

Key Features

  • Large power capacity: Provides 10kW nominal output, ideal for high-demand households and businesses.
  • High efficiency: Operates with up to 97.6% maximum efficiency, minimising energy losses.
  • Three phase operation: Delivers balanced three phase power distribution for improved system stability.
  • Battery integration: Works seamlessly with Pylontech Force-H3X battery storage systems.
  • Flexible operation modes: Supports grid-tied, off-grid, and backup applications.
  • Smart connectivity: Built-in RS485 and CAN, with optional Wi-Fi for monitoring.
  • Comprehensive protection: Safeguards against over-voltage, short circuit, overload, and overheating.
  • Rugged enclosure: IP65-rated housing ensures long-term performance in harsh environments.
  • 12-month warranty: Includes one-year manufacturer’s warranty for added assurance.

This inverter offers dependable high-capacity energy conversion, ensuring efficiency and reliability for demanding solar energy systems.

Product Specifications
Nominal Power 10000 W
Nominal AC Voltage 400 V
Nominal AC Frequency 50 Hz / 60 Hz
Max Efficiency 97.6%
MPPT Voltage Range 125 – 500 V
Max PV Input Voltage 600 V
Max Input Current 22 A + 22 A
Battery Voltage Range 100 – 600 V
Communication Interfaces RS485, CAN, Wi-Fi (optional)
Protection Rating IP65
Operating Temperature -25°C to +60°C
Dimensions (W × H × D) 550 × 516 × 191 mm
Weight 28 kg
SKU PYL.FH3X-10K-HY-3P
Model # FH3X-10K-HY-3P
Brand Pylontech
Shipping Weight 32.0000kg
Unit Of Measure ea
