This OEZ three pole fuse disconnect switch is designed for use with NH blade fuse size 1 with an Ampere rating of 250A. The holder can be panel mounted. The cover extracts fuse upon opening. Power cables are connected from the top and underside of the unit using M10 screw terminals.
Voltage: 690VAC / 440VDC - DC-21B 2 Pole Connection
Suit Fuses: NH Size 1
Mounting: Panel Mount
Front Side Protection Rating:
Built-in device, open cover: IP20.
Built-in device, closed cover, measuring holes not broken off: IP30
Approvals: IEC 60947-1,3 EN 60 947-1,3 CE
