• Low voltage-temperature coefficient enhances high-temperature operation.
  • Exceptional low-light performance and high sensitivity to light across the entire solar spectrum.
  • 25 Year limited warranty on power output and performance.
  • 5 Year Limited warranty on materials and workmanship.
  • Sealed, waterproof, multi-functional junction box gives high level of safety.
  • High performance bypass diodes minimize the power drop caused by shade.
  • Advanced EVA (Ethylene Vinyl Acetate) encapsulation system with triple-layer back sheet meets the most stringent safety requirements for high-voltage operation.
  • A sturdy, anodized aluminium frame allows modules to be easily roof-mounted with a variety of standard mounting systems.
  • Highest quality, high-transmission tempered glass provides enhanced stiffness and impact resistance.

Specifications:

  • Nominal Power (Pmpp): 20W
  • Max Power Voltage (Vmpp): 17.8V
  • Max Power Current (Impp): 1.13A
  • Open Circuit Voltage (Voc): 22.2V
  • Short Circuit Current (Isc): 1.20A
  • Cell Type: Monocrystalline
  • Number of cells in series: 36
  • Max. system voltage: 1000V
  • Temperature Range: -40°C to +85°C
  • Surface Maximum Load Capacity: 200 kg/m²
  • Allowable Hail Load: 23 m/s, 7.53 g
  • Frame: Aluminium

SKU VIC.SPM040201200
Model # SPM040201200
UPC/EAN 8719076047391
Brand Victron Energy
Shipping Weight 2.6000kg
Shipping Width 0.450m
Shipping Height 0.050m
Shipping Length 0.360m
Shipping Cubic 0.008100000m3

Purchase with confidence knowing your product is covered by the Victron 5-year manufacturer warranty.

Victron 5 Year Warranty Badge

Great Efficient Solar Panel

By: on 29 August 2025
I bought this 20w Mono solar panel to replace my old poly solar panel for my electric gates. This panel is well made and strong and puts out a high rate of current which keeps my gate battery fully topped up. It works well even in the shade that I get from nearby trees but works fantastically well in full sun. The price was great and I’m really happy with the panel.
